5
2. Front and Rear Panel
Physical Details
The following figure illustrates the front/rear panel of NAS-7103.
Front Panel View
Front LED Indication
Item LED Color Status
Power LED Blue Power on
Rear Panel View
Gigabit Ethernet
Reset button
USB host port
Power switch
Power slot
USB device port
