16-Channel Network Video Recorder
NVR-1615
26
Vendor: You may select camera vendor or use ONVIF protocol for camera connection.
Detect: Check camera available and receive camera model name.
Camera Name: Key-in camera name.
IP Address: Key-in camera’s IP address.
HTTP Port: Set up camera’s HTTP port, default is 80.
RTSP Port: Set up camera’s RTSP port for TCP streaming, default is 554.
Account: Set up the login user name of camera.
Password: Set up the login password of camera.
5.1.5 Parameter Setting
Profile:
Select video codec and resolution for live viewing and recording.
FPS: Select FPS for live viewing and recording.
Protocol: Select protocol HTTP / TCP and UDP.
Rate Control: Select EVBR or CBR for better video performance.
Quality: Select video quality by numbers.
Enable Audio: You have to enable audio for two-way audio function.
Audio Recording: Enable it for audio recording.
Two-way Audio: Enable it for Two-way Audio function.
Input Gain: Adjust the gain to reduce the input audio noise.
Output Gain: Adjust the gain to reduce the output audio noise.
The parameter dialogs are different for each vendor. It depends on camera’s
capability.
Add Camera:
1. Click “Search” button and wait for search job to finish.
2. Select a camera on search result list.
3. Preview live streaming video on preview window to confirm current camera.
4. Click “Add” button to add selected camera into system.
