Planet NVR-1615 - Upnp; Upnp Transversal; Server; Ddns

 16-Channel Network Video Recorder
NVR-1615


30
5.3.3 UPnP
Friendly Name: Display UPnP friend name on network
5.3.4 UPnP Transversal
Enable UPnP Traversal to auto-request port mapping with router, and define maximum and
minimum port value here.
Port Range: User defines.
External IP Address: User defines.
5.3.5 Server
Enable server option to start HTTP and RTSP server. When remote service is started, user is
able to connect remote service via IE browser.
HTTP Port: Set up HTTP service port here. The default setting is 80.
RTSP Port: Set up RTSP service port here. The default setting is 554.
RTSP over HTTP: Enable RTSP over HTTP function and the remote live streaming will
use HTTP protocol and HTTP port.
5.3.6 DDNS
The NVR-1615 provides PLANET DDNS function to allow you to map a domain name to the
dynamic IP address of a network device.
Sever Name: Select a DDNS server (e.g. PLANET DDNS).
Host Name: Key-in DDNS domain name.
Account: Key-in account of DDNS service.
Password: Key-in password of DDNS service.
Current IP: Click “Test” button to connect DDNS service and system will display current
public IP address.
