1.4 Specification
Model POE-152
Ethernet Connector 2 x RJ-45( 1 for data + DC out, 1 for Data in)
Ethernet Data rate 10/100/1000Mbps( vary on Ethernet device attached)
Input voltage DC 48V, 0.4A
Number of device can be powered 1
Ethernet cable TIA/EIA-568, Category 5/5e/6 cable
LED indicator 1 x power, 1 x POE ready / in-use
Operating environment 0~50 Degree C, 5%~90%RH
Storage environment -20~70 Degree C, 5%~90%RH
Dimension (W x D x H) 73 x 55 x 24 mm
Weight 50g
Emission FCC Class B, CE mark
Standard Compliance IEEE 802.3 Ethernet
IEEE 802.3u Fast Ethernet
IEEE 802.3ab Gigabit Ethernet
IEEE 802.3af Power over Ethernet
1.5 Product Outlook
LED definition:
LED Color Function
Power Yellow Lights to indicate that the POE-152 has power.
PoE ready / in-use Green Lights to indicate the port is providing 48VDC in-line power.
