Chapter 3. Installation
This section describes how to install your VF-402-KIT Video over Fiber and make
connections to the converter. Please read the following topics and perform the
procedures in the order being presented. The hardware installation of PLANET
VF-402-KIT Video over Fiber Converter do not need software conguration. To
install your VF-402-KIT on a desktop or shelf, simply complete the following steps.
3.1 Limitation
The Video over Fiber Converter does not require any software conguration. Users
can immediately use any feature of this product simply by attached the cables
and plug power on. There is some key limitation on the video over ber converter.
Please check the following items:
The device is used for Point-to-Point connection only (transmitter to receiver) and
allows video and data work on the same optical ber patch cord.
The BNC connector and supports 75 ohm cable. The distance will change by the
quality of coaxial cables.
3.2 Preparation before Installing
In order to ensure your normal use, please make sure that you are using the right
optical path, right signal, power grounding is good, and the environment meets the
requirement. We guarantee all of our products are subject to strict test and aging,
and we simulate eld environment operation tests. Please contact us if there is any
problem.
(1) Please carefully read the user manual of the product before installing.
(2) Please carefully read the safety instructions.
(3) Optical transceiver equipment shall not be disassembled by anyone without
authorization.
(4) Check the product model tag stuck outside the cabinet (T for transmitter, R for
receiver) to prevent incorrect installation.
(5) Optical transmitter is the transmitting part, its function is converting the video,
audio and data, switching value, Ethernet, etc into optical signals and then
transmitting through ber. Therefore, the device connect this type of optical
transmitter can be cradle head with cameras.
(6) Optical receiver is the receiving part, its function is converting the video, audio
and data, switching value, Ethernet, etc into electrical signals. Therefore, the
device connect this type of optical receiver can be displayer or matrix.
