Planet WDAP-W3000AX User Manual

User Manual of WDAP-C3000AX, WDAP-3000AX, WDAP-W3000AX
- 16 -
Product Specifications
Product
WDAP-C3000AX
Dual Band 802.11ax
3000Mbps Ceiling-mount
Wireless Access Point
WDAP-3000AX
Dual Band 802.11ax
3000Mbps Outdoor Wireless
AP
WDAP-W3000AX
Dual Band 802.11ax
3000Mbps Indoor
Wireless AP
Hardware Specifications
Interfaces
LAN
2 x 10/100/1000BASE-T
RJ45 port
Auto-negotiation and auto
MDI/MDI-X
PoE WAN/LAN: 1 x
10/100/1000BASE-T,
auto-MDI/MDIX, 802.3at PoE
In
PoE WAN/LANx
10/100/1000BASE-T,
auto-MDI/MDIX, 802.3at
PoE In
Antennas
Gain: 4 x Internal 4dBi
antenna (2.4G x2, 5G x2)
Four built-in N-type
connectors
Gain: 4 x Internal 1.7dBi
antenna (2.4GHz x2,
5GHz x2)
Reset Button
Reset button on the rear
side (Press over 5 seconds
to reset the device to factory
default)
Reset button (Press over 5
seconds to reset the device to
factory default)
Reset button *1
Press over 5 seconds to
reset the device to factory
default
LED Indicators
Power, SYS
Power
Power, SYS
Dimensions
(W x D x H)
168 x 168 x 32 mm
231 x 80 x 295 mm
86 x 86 x 38.8 mm
Weight
380 ± 5g
2527 g
165 ± 5g
Material
Plastic
Aluminum
Plastic
Power
Requirements
48V DC IN, 0.5A, IEEE
802.3at PoE+ (WAN/PoE
were changed port)
12V DC IN, 1.5A from DC
Jack (5.5 x 2.1mm)
48V 0.5A, IEEE 802.3at PoE+
48~54V 0.5A, IEEE
802.3at PoE+
Power
Consumption
< 15W
< 15W
< 12W
Mounting
Ceiling Mount
Mast mounting
In-wall mount
IP Level
-
IP67
-
ESD Protection
-
±8kV air gap discharge
±4kV contact discharge
-
Surge Protection
-
±20kV
-
Wireless Interface Specifications
Standard
IEEE 802.11ax
IEEE 802.11ac
