User Manual of WDAP-C3000AX, WDAP-3000AX, WDAP-W3000AX
- 80 -
4.3.5 Port Forwarding
Entries in this table allow you to automatically redirect common network services to a specific machine
behind the NAT firewall as shown in Figure 4-48. These settings are only necessary if you wish to host
some sort of server like a web server or mail server on the private local network behind your Router's
NAT firewall.
Figure 4-48: Port Forwarding
Set the function as enable or disable.
Go to the Add Port Forwarding Rule page to add a new rule.
Figure 4-49: Port Forwarding Rule Setting
Set the function as enable or disable
Enter any words for recognition.
Select the protocol type (TCP, UDP or both). If you are unsure,
please leave it to the default both protocols.
Enter the external ports you want to control. For TCP and UDP
services, enter the beginning of the range of port numbers used by
the service. If the service uses a single port number, enter it in both
the start and finish fields.
Virtual Server IP Address
Enter the local IP address.
Enter local ports you want to control. For TCP and UDP Services,
enter the beginning of the range of port numbers used by the
service. If the service uses a single port number, enter it in both the
start and finish fields.
