Planet WPG-210N User Manual

PLANET 802.11n Wireless Presentation Gateway
WPG-210N
1.4 Product Specification
Product WPG-210N
Hardware Specification
Video VGA Port: D-Sub 15-Pin female port
HDMI 1.2
Audio Out 2.5mm stereo jack
LAN 10/100Base-TX RJ-45
Interfaces
Wireless
LAN
IEEE 802.11n 300Mbps
Gain 2 x 2dBi RP-SMA detachable antenna Antenna
Orientation Omni-directional
LED Indicators Power
Material Metal
Dimension (W x D x H) 160 x 60.3 x 30mm
Weight 312g
Power External Power adaptor 5V DC input 2.6A
Wireless Interface Specification
Standard Compliance with IEEE 802.11n
Backward compatible with IEEE 802.11b/g
Frequency Band 2.412 ~ 2.4835GHz
Wireless Data Rate Up to 300Mbps
Wireless Channel America/ FCC: 2.412~2.462GHz (11 Channels)
Europe/ ETSI: 2.412~2.472GHz (13 Channels)
Japan/ TELEC: 2.412~2.4835GHz (14 Channels)
Receive Sensitivity 802.11b: 11M -76 dBm
802.11g: 54M -67dBm
802.11n: 65M (HT20) -64dBm
150M (HT40) -61dBm
Wireless Security IEEE Standard 64/128 bit WEP / WPA / WPA2-PSK
Operation Mode AP (Access Point)
AP Client
Video Display
Supported PC / Laptop
Resolution
SVGA (800x600) / XGA (1024x768)
SXGA (1280x1024) / WXGA (1280x768)
WSXGA (1440x900, 1600x1024) / UXGA (1600x1200)
WUXGA (1920x1200) / QXGA (2048x1536) / Others
Supported Output Resolution VGA:
SVGA (800x600) / XGA (1024x768)
WXGA(1280x768) / WXGA(1280x800)
WXGA (1360x768) / WXGA+ (1440x900)
HDMI:
720p (1280x720)
10
