PLANET 802.11n Wireless Presentation Gateway
WPG-210N
Chapter 2. HARDWARE INSTALLATION
Please follow the instructions below to build the wireless network connection between WPG-210N, display
equipment and your computers.
2.1 Hardware Description
2.1.1 The Front Panel
The front panel provides a simple interface monitoring the wireless presentation gateway. Figure 2-1 shows
the front panel of WPG-210N.
Front Panel
Figure 2-1 WPG-210N Front Panel
USB Port: USB 2.0 Ports for USB keyboard and mouse.
User can control the projecting PC remotely by simply plugging standard USB keyboard
or mouse into WPG-210N.
2.1.2 LED Indications
The front panel LEDs indicates instant status of system power; and helps monitor and troubleshoot when
needed. Below table show the LED indications of the Wireless Present Gateway.
LED (Green) Description
On Power On
Off Power Off
2.1.3 The Rear Panel
Rear Panel
12
