Section 2. Installing Your PX-708A Internal Drive
20
PX-708A Installation and Users Manual
Before PX-708A Installation How to Install the PX-708A
D
System uses special Cable
Select cables; all devices are
jumpered for Cable Select.
Set the PX-708A’s mode
jumper to CSEL, and connect
the drive to the end of the cable
from the computer’s IDE
interface connector.
Figure 9: How to install the PX-708A if your computer is originally set
up in configuration D
