Section 2. Installing Your PX-708A Internal Drive
16
PX-708A Installation and Users Manual
Select an IDE Configuration
Set the jumper according to the desired configuration, as shown in the
tables and illustrations on the next few pages.
NOTE
: For best CD-RW performance, try to connect the PX-708A to the
IDE port that is not connected to the hard disk drive or to a CD-ROM
drive. In most cases, this will be the secondary IDE port.
NOTE
: For best results, set the PX-708A to be the Master, if possible.
Before PX-708A Installation How to Install the PX-708A
A
Hard disks connected as
Master and Slave devices on
primary IDE port; CD-ROM
connected as Master device on
secondary IDE port.
Remove the CD-ROM drive,
change it to Slave, and re-
connect it to the secondary IDE
port.
Set the mode jumper to Master,
and connect the PX-708A as
Master device to the secondary
IDE port.
Figure 6. How to install the PX-708A if your computer is originally
set up in configuration A
