Plinius 8150 - Specifications

Plinius 8150 instruction manual. Page 11
Specifications:
150 Watts continuous power per channel into 8 ohms, both channels driven from 20Hz to
20kHz at less than 0.1% Total Harmonic Distortion from 0.25 Watts to rated output.
230 Watts continuous power per channel 20Hz to 20kHz into 4 ohms.
Dynamic headroom
1dB or greater at 8 ohms with music.
Frequency response
20Hz to 20kHz ± 0.2dB
-3dB at 5Hz, -3dB at 90kHz.
Distortion
Typically 0.05% and IM at rated power, 0.1% THD and IM worst case prior to clipping.
Saturation
180 Watts per channel or greater into 8 ohms.
Current output
35 Amps short duration continuous per channel.
Fuse protected.
Rise time
Typically 4 microseconds.
Slewing
50 Volts/uS
Hum & Noise
90dB below rated output 20Hz to 20kHz unweighted.
Input sensitivity / Input impedance
200mV RMS 47k ohms for rated output.
2mV on Phono Low gain MM. 500uV on High gain MC
Input overload
5V RMS
Rated Pre-Out level
1.5V RMS into 47k ohms or higher.
Maximum output 6V RMS into 10k ohms or higher.
Pre-Out Source impedance
Typically 5k ohms
Tape Output level / Source impedance
190mV @ 200 ohms.
Pre-Out minimum recommended load
47k ohms.
