Plinius 8150 instruction manual. Page 12
Tape loop muting
at 5V RMS input.
All operational, technical and descriptive material published here is subject to change at any time without
notice.
PLINIUS amplifiers are designed and manufactured by:
AUDIBLE TECHNOLOGIES Ltd.
P.O. Box 1836,
PALMERSTON NORTH.
NEW ZEALAND. © 1998 AUDIBLE TECHNOLOGIES
DIMENSIONS: Height : 120mm Width: 440mm Depth : 350mm Weight 15kg
Appendix 1.
To Change from Moving Magnet to Moving Coil or vis versa:
The Phono stage is that section of the upper circuit board adjacent to the Right hand side heatsink.
This task can be done by soldering the components on the top of the circuit board as through hole plating
is standard.
Fit the correct components for the required configuation from the table below.
Components Moving Moving
Number. Magnet. Coil.
R53/ R54 47000 ohms 470 ohms
R55/ R56 1000 ohms 180 ohms
R57/ R58 12000 ohms 2200 ohms
Q16/ Q18 2SC2240. Not fitted.
Q16a/ Q18a Not Fitted. 2SC4382.
