Title
Doc no.
RD07-001
Date (ISO 8601)
Best Practice
BM 2000 Systems
2007-07-05
Process owner Author Sign. Quality Section Revision Page
R&D Dept + Tech Support BOL 1 11(13)
K:\Produkte\PL88 RoHS\BM 2000 Best Practice doc
4 Software
The most recent BM 2000 software version is 1.30. Older versions are not recommended.
The
most recent VF 1008 software is 1.02
4.1 Loading Software
Some people have reported problems when loading software. If you follow the steps below there
shoul
d be no problems.
There are also unconfirmed reports about issues with some PCs in combination with the loading
equipment. Please report if you find a specific PC/hardware that won’t work properly.
SW Loading Instruction BM 2000
IMPORTANT: Perform each step in sequence as per below procedure.
1. Remove front and rear covers.
2. Note the different NVM values on the NVM value card located inside the rear cover on the
BM 2000.
3. Download software to all units according to instructions in the .exe files.
4. Remember to turn off power after download.
5. Check software versions in the service Menu in the BM2000 UI.
• UI: 1.30
• BM 2000 CPU 1.30
• BM 2000 MD6DC (B) 1.12
• BM 2000 MD6DC (C) 1.12
• FTR 2000 1.30 (If applicable)
• SQF 2000 1.30 (If applicable)
6. Perform an NVM reset according to service manual 5.1.3. in all units where software was
loaded.
• Go to service menu
• Go to NVM values
• Press reset all button
• Press Yes
7. Insert the NVM values according to the values that were noted in step 2. NVM values are
changed in the service program mode in the “changing NVM values”
8. Perform a paper size reset according to Service manual section 5.4
4.2 Known Bugs
VF 1008 V1.02: Format Selection/Internal Stacker
When running material into the internal stacker VF 1008 adopts the size settings from BM 2000,
no matter what size you specify on the VF 1008 user interface. This will be fixed in the next SW
version.
Work-around: Set desired paper size on Booklet Maker UI.
