Plockmatic BM 60 - CRI 1.2 Infeed and outfeed cover

CRI 1.2 Infeed and outfeed cover
T08010 TJ
UPPER/LOWER INFEED COVER
REMOVAL
1. Remove the two screws (1).
2. Pull out the upper end of Lower infeed cover and open cover to horizontal position.
3. Remove the screws (2) and remove the upper infeed cover.
1
2
INSTALLATION
1. Installation is an exact reversed procedure of removal.
OUTFEED COVER
REMOVAL
1. Loosen the two screws (1).
2. Pull out the upper end of cover and open to horizontal position.
1
INSTALLATION
1. Installation is an exact reversed procedure of removal.
STAPLER FOLDER MODEL 60/61 PAGE 1.2 OCTOBER-94
