4.5 Resistance
Range
Resolution
Accuracy
600 Ω
0.100 Ω
±(1.0% +5)
6 kΩ
0.001 kΩ
60 kΩ
0.010 kΩ
600 kΩ
0.100 kΩ
6 MΩ
0.001 MΩ
60 MΩ
0.010 MΩ
±(1.5% +10)
Overload protection: 250 V
4.6 Capacitance
Range
Resolution
Accuracy
6 nF
0.001 nF
±(4.0% +5)
60 nF
0.01 nF
600 nF
0.1 nF
6 μF
0.001 μF
60 μF
0.01 μF
600 μF
0.1 μF
6 mF
0.001 mF
±(5.0% +5)
60 mF
0.01 mF
Overload protection: 250 V
4.7 Frequency/Duty
Range
Resolution
Accuracy
6 Hz
0.001 Hz
±(1.0% +3)
60 Hz
0.01 Hz
600 Hz
0.1 Hz
6 kHz
0.001 kHz
60 kHz
0.01 kHz
600 kHz
0.1 kHz
6 MHz
0.001 MHz
10 MHz
0.01 MHz
1.0~99.0%
0.1%
±(1.0% +3)
Overload protection: 250 V
9
Mastering the Art of Measurement (DM401B Smart Digital Multimeter) r.01 www.plusivo.com
