Selecting the Program
The Device offers 8 different preset treatment programs respectively for TENS /EMS
modes ; the programs differ with respect to varying pulse widths and frequencies .
For TENS programs :
Program Pulse width (μS) Pulse rate (Hz) Waveform Type
P1 260 15 Constant
P2 260 60 Burst
P3 260 60 Constant
P4 260~156 2~60 Dense-Disperese
P5 260~156 60 Modulation Pulse Width
P6 260 7~60 SD Pulse Rate
P7 260~156 60 SD Pulse Width
P8 Recycle ( ( P1~P7)
For EMS programs :
All electrical specication ±10%
Pulse
Width
(μS)
Ramp up
(sec)
Hold on
(sec)
Ramp
down
(sec)
Off
Time
(sec)
Pulse rate
(Hz)
Function
Mode
P1
260 μS
(sabit)
2 3 2 2 70 5
P2 2 4 2 3 60 5
P3 2 5 2 4 50 5
P4 2 6 2 5 50 5
P5 2 2 2 6 50 A
P6 2 4 2 8 60 A
P7 2 6 2 10 70 A
P8 7~60 C
All electrical specication ±10%
