5.0 Product Specifications
Dimensions: 7.9” W x 5.5”H x 3.5”D
Weight: 8 lbs
Operating Temperature: -40º to +160º F (-40º to +70º C)
Humidity: 95% Non-condensing
Enclosure Construction: Cast Aluminum, Epoxy Powder Coat Paint Finish, Gasketed Cover
w/Captive SS Screws
Enclosure Rating: NEMA 4X, Watertight and Corrosion-proof
Power Requirements: 115 / 230 VAC Switchable, 50-60Hz, 5W Max.
Audible Alarm: 100db
Display: 9-Character, Ultra-Bright Sunlight-Readable LED Display, 0.56” Ht, Readable from 25’
Ultra-Bright Intensity Alarm LEDS, Visible from 75’
Display Data: Gross/Net Volumes, Percent Volume, Ullage, Product Level, Water Level, Product
Temperature, Tank Name, Tank ID, Tank Alarms
LED Display Mode Indicators: Volume, Percent Volume, Ullage, Product Height, Water Height,
Product Temperature
LED Alarm Indicators: In-Tank Leak, Three Product Setpoints, Water Setpoint
Communications: TMS Series Peripheral Expansion Bus
Communications Format: RS-485, Half-Duplex
Connection Type: Plug-In Terminal Block with Wire Entries
Input: Ch. A (+), Ch. B (-), Shield
Output: Ch. A (+), Ch. B (-), Shield
Recommended RS-485 Cable: Belden 9841 (PVC Jacket), 89841 (FEP Teflon Jacket) or similar
Maximum Cable Length: 4000 Feet/1200 Meters total to end of run
Slave Address Select: 1 thru 16, Rotary Dip Switch Selectable
Display Update Rate from TMS: 400 to 600 milliseconds (0.4 to 0.6 seconds)
