5 User manual
English
Technical specifications
» Engine working temperature: -26°C ~ + 80°C
» Control unit power supply: 230V
» Power: 350W
» Transmission mode output: M = 4
» Torque: 30.0 N.m
» Opening / closing speed: 12m / min
» Rotations: 1400rpm
» Pull force: 1100N (Newton)
» Maximum load supported: 800 kg
» Maximum communication distance with remote control: 50 m
Main features
» Possibility to connect the photocell (included), access keyboard, access
button and other access control accessories
» Possibility to connect the safety lamp (included)
» Automatic closing
» Adjustable sensitivity
Dimensions:
Important notes
» Power the control unit to a separate 10A power supply.
» Keep a distance between the rack and the gear of the engine so as not to
overload the engine.
