Point Mobile PM84 - Page 74

PM84 Android 13 User Manual
Accessories
73
© 2023 Point Mobile Co., Ltd. All rights reserved
Attach hand strap
1. Using the arrow-like side of the strap through the hand strap hole.
2. Insert the arrowhead into the small hole of the hand strap and pass it through the neck.
3. Thread the opposite side of the strap through another hand strap hole.
Figure 92 Attaching hand strap - 1
Figure 93 Attaching hand strap - 2
Figure 94 Attaching hand strap - 3
