point Vitap - Page 16

Rel. 03
15
- USB gate for PC interface “1”
- Luminous engine button “2”
- Emergency stop “3”
- Key selector for horizontal extra-stroke reset “4”
- Button Start “5”
- Button +/- “6”
- Optional output selector panel. “8”
- Keyboard and mouse for PC interface “7”
- Reducer filter group
- Pressurers activation electrical pedal levers
- Button placement the left roller
- Frontal stop
7
1 2 3
5
4 6 8
