Rel. 03
46
1 2 3
5
4 6 8
Activations
In this modality it is possible to start the machine components separately.
Select one of the button on the screen and then press button + or
– (n° 6 of the picture)
For every splinde existing the following buttons are foreseen:
- ON = spindle engine start
- MOVE = group displacement
For every axis (X, Z in the picture) the “MOVE” button only is foreseen
7.5 MILLIMETRES/INCHES
1) On software Press the button
2) Press the button shown in the picture
