How to install a printer on a Network
4.3 Network Conguration Setting (Option)
Install Network driver “automatically or by manually clicking Install.exe” le.
1
“Tick Card Printer Driver box”
2
“Tick Network Software” box then “Click Next” button.
3
“Click the Agree option then click the Next button”.
4
If you get a Windows Security Warning Message pop-up, “Click Allow Access” button.
5
“Click Network Printer”.
6
If the printer is connected to your network and you are using DHCP mode, the IP address
will automatically appear in the drop down box. If the IP address is correct, “Click the
Next” button.
6-1
If IP address is not shown in the drop down box, tick input by user and then click Cong
button. The Conguration window will pop up and you can select the right MAC address
on the board list on the left side. You can also check the information for the Network
Setting, which is automatically assigned from your DHCP server. If the information is
correct, please “Click the Setting” button at the bottom. If the setting is ok, the printer
will “Re-boot automatically and Network setting complete” will pop up.
If the addresses are not correct, you can edit and then click setting to save.
6-2
<Network Conguration Window>
Printer Driver Settings Printer Driver Settings
