120
MAINTENANCE
Track Maintenance
Track Tension
Track adjustment is critical for proper handling. Always maintain cor-
rect tension and alignment.
NOTE: Tension adjustments should be made only after the track is
warmed up and limber.
1. Turn the engine off.
2. Lift the rear of the machine and safely support it off the ground.
3. Place the recommended weight or downward pressure on the track
at the specified distance (see chart) ahead of the center of the rear
idler wheel.
NOTE: Measure at the point where the weight is hanging.
WARNING
Moving parts can cut and crush body parts. When performing the checks and
adjustments recommended on the following pages, stay clear of all moving
parts. Never perform track measurement or adjustments with the engine run-
ning.
TRACK TENSION DATA CHART
Suspension Slack Measurement Weight
Measurement
Location
IQ 121 7/8"-1 1/8" (2.2-2.9 cm)
10 lbs.
(4.54 kg)
16" (40 cm)
ahead of rear
idler shaft
Switchback 136 7/8"-1 1/8" (2.2-2.9 cm)
M-10 128 7/8"-1 1/8" (2.2-2.9 cm)
M-10 136 7/8"-1 1/8" (2.2-2.9 cm)
