THE PERFECT FIT
Handlebar Adjustments
Use the RIDER SELECT feature to adjust handlebar position. See page
29. Use the following steps to adjust handlebar angle at the handlebar
block.
1. Remove the handlebar cover to
expose the handlebar and the
four adjuster block bolts.
NOTE: If equipped, remove the
mountain bar.
2. Using a 7/16" wrench, loosen
the four nuts on the bottom of
the adjuster block (turn handle-
bar to left or right for access to
back nuts).
NOTE: If necessary, pry the blocks
apart with a screwdriver.
3. Adjust the handlebar to the
desired height. Be sure handle-
bars, brake lever and throttle
lever operate smoothly and do
not hit the gas tank, windshield
or any other part of the machine
when turned fully to the left or right.
4. Torque the front bolts first, then torque the rear bolts. Torque the
bolts to 11-13 ft. lbs. (15-18 Nm).
5. Reinstall the handlebar cover.
Handlebar
Cover
Adjuster
Block
Bolts
Nuts
