34
FEATURES
Instrumentation
MFD Component Identification
Digital Display Identification
Item
1 Analog (if equipped)
2 Digital Gauge
3 CHECK ENGINE
Indicator (carb models)
4 Low Oil Indicator
5 High Temp Indicator
6 Brake Indicator
7 Reverse Indicator
8 High Beam Indicator
Item
1 RPM or Speed
Altitude (if equipped)
Service Interval
2 Electrical System
Voltage Level
3 MAX - Maximum MPH/
KPH or RPM
MPH -Miles per hour
KPH - Kilometers per hour
RPM -Engine crankshaft
revolutions per
minute
4 Air Temp (if equipped)
Engine Temp
Degrees Celsius
Degrees Fahrenheit
5Miles
Kilometers
6Hours
Trip 1/Trip 2/Trip F
Service Label
Altitude Label
7 Fuel Level (if equipped)
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
