32
FEATURES
Backrest (Touring)
The backrest is adjustable for either
operator or passenger use.
1. Loosen the upper adjustment
knobs to raise or lower the
backrest.
2. Loosen the lower adjustment
knobs to move the backrest
forward for operator use or
rearward for passenger use.
3. Always tighten the knobs
securely after adjusting.
Passenger Grab Handle
On some Touring models the position
of the passenger grab handles can be
adjusted for rider preference.
1. Unscrew and remove the knob
assemblies that secure the grab
handles.
2. Reposition the grab handles to
one of the three available posi-
tions on the grab handle tube
between the operator seat and the
passenger seat.
3. Reinstall the knob assemblies and
tighten securely.
Radiator Compartment Access Panel
The access panel is provided for
cleaning debris from the radiator.
Operator/Passenger
Raise/Lower
Knob
Assembly
