129
MAINTENANCE
Battery (if equipped)
WARNING! Improperly connecting or disconnecting battery cables can result in
an explosion and cause serious injury or death. When removing the battery,
always disconnect the negative (black) cable first. When reinstalling the battery,
always connect the negative (black) cable last.
Battery Removal
CAUTION! Hot exhaust system parts can cause burns. Allow adequate time for
the exhaust system to cool. Never perform this procedure with the engine
running.
1. Remove the right side panel.
2. Remove the two plastic
rivets (1) securing the
console panel to the chassis.
3. Remove the plastic rivet (2)
securing the fender to the
chassis.
4. Remove the rubber hold-
down strap (3).
5. Disconnect the black
(negative) battery cable first.
6. Disconnect the red (positive)
battery cable last.
