MAINTENANCE
Hood Removal and Installation
1. Remove the side panels.
2. Rotate the 1/4-turn fasteners
at the upper corners of the
hood.
3. Disconnect the wire harness
leading to the console
electronics.
4. Remove the hood assembly.
5. To reinstall the hood, slide
the nose clips into the
nosepan.
6. Position the hood and align
the 1/4-turn fasteners at the
back of the hood. Secure the
fasteners.
7. Reconnect the wire harness.
8. Reinstall the side panels.
