2 - 14 SUSPENSION AND STEERING
GEM Service Manual November 2007
Fig. 11 Steering Wheel Holes For Puller Fig. 12 Wheel Puller Installed
1 - Guide holes
INSTALLATION
1. Using reference marks, align steering wheel to steering shaft and place on shaft.
2. Replace washer and attaching nut on end of shaft and tighten to press wheel completely on splines. Back
off nut and tighten to 20 ft-lbs.
3. Replace steering wheel cover and attach with mounting screws.
TORQUE SPECIFICATIONS
Description Thread Size Use
Loctite®
242
Inch-
Pounds
Foot -
Pounds
Steering wheel to steering shaft
NO --- 20
