119
Maintenance
Spark Arrester
1. Remove the six bolts and remove the
arrester from the end of the muffler.
2. Use a non-synthetic brush to clean the
arrester screen. A synthetic brush may
melt if components are warm. If necessary,
blow debris from the screen with
compressed air.
3. Inspect the screen for wear and damage.
Replace the arrester if damage is found.
4. Reinstall the arrester.
5. Torque the bolts to 7 ft. lbs. (9.5 Nm).
Arrester Screen
