160
Specifications
SPORTSMAN 110
Rider Capacity/Maximum Weight 1 Rider/180 lbs. (81.7 kg)
Dry Weight 289 lbs. (131 kg)
Length/Width/Height 61.75" (157 cm) / 36.75" (93 cm) / 38.5" (98 cm)
Wheel Base 41.5" (105 cm)
Ground Clearance 4" (10 cm) at swing arm, 7.7" (19.5 cm) at frame
Engine type 4-Stroke
Displacement 111cc
Cooling Air Cooled
Bore x Stroke 61 mm x 57.8 mm
Alternator Output 80 watts
Compression Ratio 9.5:1
Lubrication Wet Sump
Oil Capacity 30 oz. (900 ml)
Fuel Capacity 2 gallons (7.7 liters)
Fuel Reserve Capacity .22 gallons (.85 liters)
Starting System Electric
