Instr 9927474 Rev 01 2017-02 Page 2 of 14
REF
QTY PART DESCRIPTION
PART NUMBER
9 1 Rope 2878888
10 1 Winch Cable, Yellow 6 GA 300mm 4013468-300
11 1 Winch Cable, Blue 6 GA 300mm 4013469-300
12 1 Power Cable, Black #6 530mm 4013470-530
13 1 Power Cable, Red #6 510mm 4013471-510 WC
14 1 Contactor 4015095
15 1 Autostop Fairlead 5140385
16 1 Stop Magnet 5415787
17 4 Screw Torx
®
Head - M8 X 1.25 X 20
-
18* 2 Screw - M6 X 1.0 X 25
-
19* 2 Screw - M10 X 1.5 X 25
-
20* 2 Nut - M10 X 1.5
-
1 Winching Guide 9923644
1 Instructions 9927474
Service Handle (includes freespool handle and screw) 2205265
Items marked (*) are included in Hardware Kit (PN 2880643).
TOOLS REQUIRED
• Safety Glasses
• Socket Set, Metric
• Screwdriver, Phillips
• Wire Cutter
• Hex Key Set, Metric
• Socket Set, Torx
®
Bit
IMPORTANT
Your SPORTSMAN
®
XP POLARIS
®
PRO HD WINCH KIT is exclusively designed for your vehicle. Please read
the installation instructions thoroughly before beginning. Installation is easier if the vehicle is clean and free of
debris. For your safety, and to ensure a satisfactory installation, perform all installation steps correctly in the
sequence shown.
ASSEMBLY TIME
Approximately 40 minutes
