10
9928485 R01 - 2017-2018 RANGER 500 / 570 Service Manual
© Copyright Polaris Industries Inc.
10.13
CREW FLOOR / REAR FENDERS
REF.
DESCRIPTION NOTES
q
Front Floor
w
Main Floor
e
Front Seat Panel
r
Rear Main Floor
t
Storage Box
y
Front Inner Fender
u
Cup Holder
i
Floor Cover
o
Push Rivet
BODY / FRAME
