100
SPECIFICATIONS
RANGER 4X4 XP
Gross Vehicle Weight 2750 lbs. (1247 kg)
Dry Weight 1185 lbs. (537 kg)
Fuel Capacity 8gal.(30.3l)
Engine Oil Capacity 2qts.(2.1l)
Coolant Capacity 3.25 qts. (3 l)
Towing Capacity 1500 lbs. (681 kg)
Hitch Tongue Capa city 150 lbs. (68 kg)
Max. Cargo Box Load 1000 lbs. (454 kg)
Overall Length 113 in. (282 cm)
Overall Width (box) 60 in. (152.4 cm)
Overall Width (tires) 58 in. (147.3 cm)
Overall Height 75 in. (190.5 cm)
Wheelbase 76 in. (193 cm)
Cargo Box
(LxWxH)
58x42x10in.
(147 x 106.7 x 25.4 cm)
Ground Clearance 11.5 in. (29 cm)
Min. Turning Radius 132 in. (335.3 cm)
Engine 4 valve 4 stroke twin cylinder with
counter balance
Displacement 683 cc
Bore x Stroke 80x68
Alternator Output 500 W @ 3000 RPM
Compression Ratio 9.40:1
Starting System Electric
Fuel System Electronic Fuel Injection
Ignition System ECU
SparkPlug/Gap RC7YC / .035 in. (0.9 mm)
Front Suspension MacPherson strut
w/8 in. (20.3 cm) of travel
Rear Suspension Independent
w/9.0 in. (22.9 cm) of travel
