32
FEATURES AND CONTROLS
Brake Pedal (1)
Depress the brake pedal to slow or stop the vehicle.
Apply the brakes while starting the engine.
Throttle Pedal (2)
Push the pedal down to increase
engine speed. Spring pressure
returns the pedal to the rest
position when released. Always
check that the throttle pedal
returns normally before starting
the engine. Make sure there’s
adequate throttle pedal freeplay.
See page 81 for throttle pedal
adjustment procedures.
Park Brake Pedal (3)
Engage the park brake when parking the vehicle to help prevent the
vehicle from rolling. To engage the park brake, apply the brakes, then
push the park brake pedal down firmly and fully with your foot.
Park Brake Release (4)
Always apply the service brakes before releasing the park brake. To
release the park brake, pull the park brake release handle. Make sure
the park brake pedal is functioning properly before each operation.
