23
FEATURES AND CONTROLS
Some Polaris vehicles are equipped with special features such as the
cab frame. Not all models come with all features. Refer to the
specifications section beginning on page 100.
Component Locations
1. Cab Frame (if equipped)
2. Hip Bar
3. Console
4. Steering Wheel
5. Seat
6. Storage Box (under driver’s seat)
7. Cargo Box
8. Seat Belts
9. Fuel Tank Cap / Fuel Gauge
10. Battery (under hood)
11. Storage Box (under hood)
1
4
8
5
7
2
3
9
10
6
