102
SPECIFICATIONS
RANGER 6X6 EFI
Gross Vehicle Weight 2900 lbs. (1317 kg)
Dry Weight 1410 lbs. (640 kg)
Fuel Capacity 8gal.(30.3l)
Engine Oil Capacity 2qts.(2.1l)
Coolant Capacity 3.25 qts. (3 l)
Towing Capacity 1750 lbs. (794 kg)
Max. Cargo Box Load 1250 lbs. (567 kg)
Overall Length 120 in. (304.8 cm)
Overall Width (box) 60 in. (152.4 cm)
Overall Width (tires) 58 in. (147.3 cm)
Overall Height 75 in. (190.5 cm)
Wheelbase 90 in. (228.6 cm)
Ground Clearance 7.2 in. (18 cm )
Min. Turning Radius 180 in. (457.2 cm)
CargoBox(LxWxH) 58x48x10in.
(147 x 122 x 25.4 cm)
Engine 4 valve 4 stroke twin cylinder
with counter balance
Displacement 683 cc
Bore x Stroke 80x68
Alternator Output 500 W @ 3000 RPM
Compression Ratio 9.40:1
Starting System Electric
Fuel System Electronic Fuel Injection
Ignition System ECU
SparkPlug/Gap RC7YC / .035 in. (0.9 mm)
Lubrication System Pressurized Wet Sump
Engine Oil 0W/40
