1
2
1
2
6X6
4X4
68
MAINTENANCE AND LUBRICATION
Gearcases
Rear Gearcase
Always check and change the rear gearcase oil at the intervals outlined
in the Periodic Maintenance Chart beginning on page 53.
Refer to the Gearcase Specifications Chart on page 63 for
recommended lubricants, capacities and torque specifications. See
page 99 for the part numbers of P olaris products.
The rear gearcase fill plug (1) is on the drivers side of the rear
gearcase.
Oil Check (6X6)
The easiest way to check for adequate oil in the 6X6 is to drain and
refill the gearcase to capacity (see page 63). Perform the oil change as
outlined on page 69.
Oil Check (4X4)
Maintain the oil level 3/4 of an inch
(19 mm) below the bottom thread of
the fill plug hole. Use a light colored
non-absorbent measuring instrument
(such as a white cable tie) to measure
the depth.
1. Position the vehicle on a
level surface.
2. Remove the fill plug. Check
the oil level.
3. Add t he recommended
oil as needed.
4. Reinstall the fill plug.
Torque to specification.
