84
MAINTENANCE
General Maintenance
Drive Chain Tension
To obtain correct chain tension:
1. Rotate the driven clutch
counterclockwise t o move all chain
slack to the tensioner side. Lock
the brake lever lock, or have an
assistant hold the brake lever
firmly.
2. Loosen the adjuster bolt jam nut
(A).
3. Fi nger tighten the adjuster bolt (B)
until it can no longer be adjusted
by hand, then back off 1/4 turn.
4. Tighten the jam nut while holding
the adjuster bolt.
5. The chain is now tensioned.
Release the brake lever lock.
A
B
