90
MAINTENANCE
General Maintenance
NOTE: Avoid touching a halogen bulb with bare fingers. Oil from
skin leaves a residue, causing a hot spot that will shorten the life of the
lamp.
Removing Halogen Bulbs
1. P inch the ends of the spring (1)
together and lift until it releases
from the spring retainer.
2. Lift spring carefully around wire
harness (2) and flip to outside of
housing.
3. With the wire harness attached
to the bulb (3), withdraw bulb
from housing.
4. Grasp bulb by metal base and
carefully separate bulb from
harness.
Installing Halogen Bulbs
1. Hold bulb by metal base and install into wire harness.
2. Insert bulb into housing.
3. Carefully flip spring back into housing placi ng it around wire
harness.
4. Squeeze spring together until it is over the spring retainer and
release.
5. Verify headlight aim.
2
1
3
