9926814 R08 - 2015-2016 RZR 900 2016 RZR S 1000 Service
Manual
© Copyright Polaris Industries Inc.
4.3
GENERAL INFORMATION
TORQUE SPECIFICATIONS
COMPONENT TORQUE
CPS Fastener
9 ft-lb (12 Nm)
ECU Mounting Screws 24 in-lb (3 Nm)
Fuel Rail Mounting Screws 5 ft-lb (7 Nm)
Fuel Tank PFA Nut
70 ft-lbs (95
Nm)
Fuel Tank Strap Fasteners
8 ft-lbs (11
Nm)
TMAP Fastener
5 ft-lb (7 Nm)
SPECIAL TOOLS
PART NUMBER
TOOL DESCRIPTION
PU-43506–A
Fuel Pressure Gauge Kit
PV-48656
Fuel Pressure Gauge
Adapter (900)
PA-48838
Fuel Pressure Gauge
Adapter (1000)
PU-47063–B Digital Wrench Diagnostic
Software (includes CD w/
serial number, interface
cable, USB serial adapter
cable and Smartlink
Module Kit)
Bosch Automotive Service Solutions:
1-800-345-2233 or http://polaris.service-solutions.com/
FUEL SYSTEM
