9926814 R08 - 2015-2016 RZR 900 2016 RZR S 1000 Service
Manual
© Copyright Polaris Industries Inc.
60″ (S / 4 900) models
FRONT
REAR
Shock Travel
q
6.72″ (17.07 cm) 7.52″ (19.10 cm)
Extended Length
w
22.52″ (57.20 cm) 22.47″ (57.07 cm)
IFP Depth
e
3.00″ (7.62 cm) 3.20″ (8.13 cm)
Nitrogen Pressure
100 PSI (690 kPa)
Gas Shock Oil 2874124 (qt)
Compression Adjustment (factory)
r
12 clicks CCW from full stop
Spring Adjustment Setting (factory)
t
S: 7.39″ (18.77 cm)
4 900: 6.08″ (15.45 cm)
S: 2.80″ (7.11 cm)
4 900: 1.15″ (2.92 cm)
60″ (S) Front Shock Valving
COMPRESSION REBOUND
1.600 x .008 DB 1.425 x .008
1.600 x .008 1.425 x .008
1.600 x .008 1.425 x .008
1.600 x .008 0.800 x .006
0.750 x .008 1.425 x .012
1.600 x .012 1.350 x .012
1.600 x .012 1.250 x .012
1.600 x .012 1.100 x .012
1.600 x .012 0.950 x .012
1.600 x .012
1.230 x .082 Top Out
1.600 x .012 0.750 x .100 Back Up
1.100 x .006
1.570 x .128 Top Out
60″ (S) Rear Shock Valving
COMPRESSION REBOUND
1.600 x .006 DB 1.425 x .010
1.600 x .010 1.425 x .010
1.600 x .010 1.425 x .008
1.600 x .010 0.950 x .006
1.050 x .006 1.425 x .020
1.600 x .015 1.425 x .020
1.600 x .015 1.425 x .020
1.425 x .015 1.425 x .020
1.425 x .015 1.250 x .015
1.350 x .015
1.230 x .082 Top Out
1.350 x .015
1.250 x .015
1.250 x .015
1.100 x .015
1.570 x .128 Top Out
60″ (4 900) Front Shock Valving
COMPRESSION REBOUND
1.600 x .008 DB 1.425 x .012
1.600 x .008 1.425 x .012
1.600 x .008 1.425 x .012
1.600 x .008 1.425 x .012
1.600 x .008 1.425 x .012
1.600 x .008 0.800 x .006
0.750 x .004 1.425 x .015
1.600 x .012 1.350 x .015
1.600 x .012 1.250 x .015
1.600 x .012 1.100 x .015
1.600 x .012 0.950 x .015
1.600 x .012 1.230 x .082 Top Out
1.600 x .012 0.750 x .100 Back Up
1.100 x .004
1.570 x .128 Top Out
60″ (4 900) Rear Shock Valving
COMPRESSION REBOUND
1.600 x .010 SB 1.425 x .008
1.600 x .008 1.425 x .008
1.600 x .008 0.950 x .006
1.050 x .008 1.425 x .015
1.600 x .008 1.425 x .015
.950 x .008 1.425 x .015
1.600 x .015 1.425 x .015
1.425 x .015 1.425 x .015
1.425 x .015 1.425 x .015
1.350 x .015 1.250 x .015
1.350 x .015 1.230 x .082 Top Out
1.250 x .015
1.250 x .015
1.100 x .008
1.570 x .128 Top Out
