9.32
9926814 R08 - 2015-2016 RZR 900 2016 RZR S 1000 Service
Manual
© Copyright Polaris Industries Inc.
TROUBLESHOOTING
BRAKE NOISE TROUBLESHOOTING
Dirt or dust buildup on the brake pads and disc is the most common cause of brake noise (squeal caused by vibration).
If cleaning does not reduce the occurrence of brake noise, Permatex™ Disc Brake Quiet can be applied to the back of
the pads. Follow directions on the package. This will keep pads in contact with caliper piston(s) to reduce the chance
of squeaks caused by dirt or dust.
Brake Noise Troubleshooting
POSSIBLE CAUSE REMEDY
Dirt, dust, or imbedded material on pads or disc
Spray disc and pads with CRC Brakleen™ or an
equivalent non-flammable aerosol brake cleaner.
Remove pads and/or disc hub to clean imbedded
material from disc or pads.
Pad(s) dragging on disc due to:
Improper adjustment
Master cylinder reservoir overfilled
Master cylinder compensating port restricted
Master cylinder piston not returning completely
Caliper piston(s) not returning
Operator error (riding the brake)
Adjust pad stop (front calipers)
Set to proper level
Clean compensating port
Inspect. Repair as necessary
Clean piston(s) seal
Educate operator
Loose wheel hub or bearings
Check wheel and hub for abnormal movement.
Brake disc warped or excessively worn Replace disc
Brake disc misaligned or loose Inspect and repair as necessary
Noise is from other source (axle, hub, disc or wheel)
If noise does not change when brake is applied check
other sources. Inspect and repair as necessary
POOR BRAKE PERFORMANCE
• Air in system
• Water in system (brake fluid contaminated)
• Caliper or disc misaligned
• Caliper dirty or damaged
• Brake line damaged or lining ruptured
• Worn disc and/or friction pads
• Incorrectly adjusted stationary pad
• Worn or damaged master cylinder or components
• Damaged break pad noise insulator
• Brake pads dragging
• Brake caliper dragging
PEDAL VIBRATION
• Disc damaged
• Disc worn (runout or thickness variance exceeds
service limit)
CALIPER OVERHEATS (BRAKES DRAG)
• Compensating port plugged
• Pad clearance set incorrectly
• Parking brake lever incorrectly adjusted (INT’L Model)
• Brake pedal binding or unable to return fully
• Parking brake left on (INT’L Model)
• Residue build up under caliper seals
• Operator riding brakes
BRAKES LOCK
• Alignment of caliper to disc
• Caliper pistons sticking
• Improper assembly of brake system components
BRAKE SYSTEM
