Polaris RZR 900 2016 Service Manual

9926814 R08 - 2015-2016 RZR 900 2016 RZR S 1000 Service
Manual
© Copyright Polaris Industries Inc.
1.11
ENGINE
Platform
Domestic Twin Cyl., 4–Stroke,
DOHC
Engine Displacement
875 cc
Number of Cylinders
2
Bore & Stroke 93 x 64.4 mm
Compression Ratio
10.5:1
Engine Idle Speed
1250 +/- 100 RPM
Engine Max Speed
8300 RPM
Engine Hot Light
Instrument Cluster Indicator
Lubrication
Wet Sump
Oil Requirements
PS4
Oil Capacity 2.5 qts. (2.4 L)
Coolant Capacity 5.0 qt (4.7 L)
FUEL SYSTEM
Type
Bosch ME17 EFI
Fuel Delivery Electronic Fuel Pump (in-tank)
Fuel Pressure
58 ± 2 PSI (400 ± 14 kPa)
Fuel Capacity /
Requirement
9.5 gal. (36 L)
87 Octane (minimum)
ELECTRICAL
Alternator Max Output 560 Watts @ 3000 RPM
Lights: Main Headlights Dual Beam 55/60W Halogen
Taillights
0.2 Watt LED cluster
Brake Lights
2.9 Watt LED cluster
Ignition System
ME17 ECU
Spark Plug / Gap
NGK MR7F/ 0.7–0.8 mm
Battery / Amp Hr
12v Flooded, 575 CCA
DC Outlet Standard 12 Volt
Relays
Fan, EFI, Fuel Pump, Chassis,
EPS (if appl.)
Circuit Breaker
20A Cooling Fan
Fuses
10A EFI
10A Key
10A Term
10A Accessory
10A Drive
15A Lights
20A EPS (if appl.)
DRIVETRAIN
Transmission Type
Polaris Automatic PVT
Shift Sequence
In Line Shift - P / R / N / L / H
Transmission Gear Ratios:
High
Low
Reverse
10.4:1
18.8:1
22.92:1
Front Gearcase Lubricant
Requirement
Demand Drive
7.5 oz. (222 ml)
Transmission Lubricant
Requirement
Full Synthetic AGL
44 oz. (1300 mL)
STEERING / SUSPENSION
Toe Out
1/8 - 3/16″ (3.2 - 4.8 mm)
Front Suspension
Independent Dual A-arm
Sachs Shocks
Front Travel
10″ (25.4 cm)
Rear Suspension
Independent Dual A-arm
Sachs Shocks
Rear Travel
10″ (25.4 cm)
Spring Adjustment
Threaded Spanner Wrench
Adjustment
WHEELS / BRAKES
Front Rim / Size
Steel
12 x 6
Rear Rim / Size
Steel
12 x 8
Front Tire Make / Model /
Size
PXT
26 x 8 R12
Rear Tire Make / Model /
Size
PXT
26 x 9 R12
Tire Air Pressure
Front
10 psi (69 kPa)
Rear
12 psi (83 kPa)
Brake System
Front & Rear
Foot Actuated 4 Wheel
Hydraulic – Dual Bore Caliper
Brake Fluid DOT 4
For clutch specifications / High Altitude setup, see PVT
System chapter – Clutch Charts, page 5.4
GENERAL INFORMATION
1

Polaris RZR 900 2016 Specifications
