Polaris RZR 900 2016 Service Manual

6.2
9926814 R08 - 2015-2016 RZR 900 2016 RZR S 1000 Service
Manual
© Copyright Polaris Industries Inc.
GENERAL INFORMATION
TORQUE SPECIFICATIONS
COMPONENT TORQUE
Bell Crank Nut
18 ft-lb (24
Nm)
Differential Cover Screws
22 ft-lb (30
Nm)
Engine to Transmission Fasteners
Sector Gear Cover Bolts
12 ft-lb (16
Nm)
Shift Cable Bracket Bolts
17 ft-lb (23
Nm)
Snorkel Locking Screw
10 ft-lb (14
Nm)
Transmission Bearing Cover Screws
10 ft-lb (14
Nm)
Transmission Case Bolts
20 ft-lbs (27
Nm)
Transmission Drain / Fill Plug
14 ft-lbs (19
Nm)
Transmission Isolator Fasteners
(rear)
33 ft-lb (45
Nm)
Transmission Mount Bracket
Fasteners (rear)
22 ft-lb (30
Nm)
SPECIAL TOOLS
PART NUMBER TOOL DESCRIPTION
PA-50231 Snorkel Tool
2871698
(Part of 2871702 Kit)
Rear Output Seal Driver
2871699
(Part of 2871702 Kit)
Rear Driveshaft Seal Guide
2871282
Bearing Seal Driver (50 mm)
PU-50566 Transmission Nut Socket
PU-50658-A Clutch Center Distance Tool
Bosch Automotive Service Solutions:
1-800-345-2233 or http://polaris.service-solutions.com/
LUBRICATION SPECIFICATIONS
FLUID CAPACITY
Recommended Transmission Lubricant:
AGL (PN 2878068) (Quart)
Capacity (Standard): 44 oz. (1300 ml)
Capacity (INT’L): 40.5 oz. (1200 ml)
TRANSMISSION

Polaris RZR 900 2016 Specifications

General

Brand	Polaris
Model	RZR 900 2016
Category	Offroad Vehicle
Language	English
