8.40
9926814 R08 - 2015-2016 RZR 900 2016 RZR S 1000 Service
Manual
© Copyright Polaris Industries Inc.
NOTE
When installing bleed shim, ensure the tab is lined up
with compression port.
28.Install rebound valve stack with required top out
washer.
29.Apply a thin layer of float fluid to the threads, nut, or
BOC post and torque to 22 ft-lbs (30 Nm).
30.Install BOC post valving.
NOTE
Ensure retaining ring is fully installed and secure.
31.Install BOC piston and retaining ring.
32.Apply Loctite® primer to the body cap threads.
33.Install appropriate O-ring and apply a thin layer of
shock oil to the O-ring ONLY.
STEERING / SUSPENSION
