9940259 R02 - 2022 RZR PRO R / PRO R 4 Service Manual
© Copyright Polaris Industries Inc.
ENGINE DISASSEMBLY / INSPECTION - BOTTOM END
OIL PAN REMOVAL
NOTICE
The oil pump drive chain must be removed before the
oil pan can be removed.
Remove the oil pan bolts.
IMPORTANT
Use the pry points on the oil pan to release the seal
between the crankcase and the oil pan.
LOWER CRANKCASE REMOVAL
1. Remove the bedplate perimeter fasteners and the
main fasteners.
IMPORTANT
Do not forget the 2 outside rear fasteners.
2. Using the pry-points and an appropriate prying tool,
gently separate the upper and lower crankcase.
ENGINE / COOLING SYSTEM
