116
SPECIFICATIONS
2004 Scrambler 500 4x4
Jetting Chart
Altitude AMBIENT
TEMPERATURE
Below 40° F
(Below 5° C)
+40°F and above
(+5°C and above)
Meters
(Feet)
0-1800
(0-6000)
160 155
1800-3700
(6000-12000)
152.5 147.5
Clutching Chart
Altitude Shift
W eight
Drive Clutch
Spring
Driven Clutch
Spring
Helix/Spring
Setting
Meters
(Feet)
0-1800
(0-6000)
10WH
5630710
Blue/Green
7041157
Silver
7041499
40°
5131446
1+1
1800 & above
(6000 & above)
10RH
5630709
Blue/Green
7041157
Silver
7041499
40°
5131446
1+1
