37
FEATURES AND CO NTRO LS
Electrical Switches
Activating the override switch while the throttle is open can
cause loss of control, resulting in severe injury or death. Do not
activate the override switch while the throttle is open.
WARNING
Override Switch (1) (Reverse Speed Limiter) -
This vehicle is equipped with a reverse speed limiter
system. To gain additional power while backing,
depress the override switch. NOTE: The override
switch also allows activation of AWD in reverse, if
the AWD switch is on.
Main Switch (2) - To start the engine, slide t he stop switch to the
center RUN position and turn the main key switch clockwi se past the
ON position. Release the key when the engine starts. NOTE: Turn off
the main switch to end all electrical power to the vehicle, including the
lights.
Engine Stop Switch (3) - The engine will not start or run when the
switch is i n its OFF position. Its purpose is to provide the operator
with a quick means of engine shutdown in case of an emergency. To
stop the engine, slide the stop switch either right or left to the OFF
position. NOTE: Turning off the engine stop switch will shut off all
electrical power to the vehicle, including the lights.
1
2
3
RUN OFFOFF
3
Leaving the keys in the ignition can lead to unauthorized use of
the vehicle resulting in serious injury or death. Always remove
the ignition key when the vehicle is not in use.
WARNING
